1-1/2 HP Air Heavy Duty Direct Drive Flange Mount Mixer

1-1/2 HP Air Heavy Duty Direct Drive Flange Mount Mixer Image
1-1/2 HP Air Heavy Duty Direct Drive Flange Mount Mixer - image 1
1-1/2 HP Air Heavy Duty Direct Drive Flange Mount Mixer - image 2
1-1/2 HP Air Heavy Duty Direct Drive Flange Mount Mixer - image 3
1-1/2 HP Air Heavy Duty Direct Drive Flange Mount Mixer - image 4

Model Number: FM-150A

Part Number: 21Q2740

INDCO's deluxe heavy duty flange mount mixers are an excellent choice for mixing in large scale process vessels or anywhere sealed mixing is required.  Simply the best value in the industry for this type of mixer,  the FM-075A model features a 304 stainless steel 4" ANSI flange mount design and a dry-running mechanical seal rated 125 psi to full vacuum.  The 1-1/2 HP air motor provides maximum agitation when supplied with 100 PSI @ 70 CFM.  See our air motor performance guide for operation at lower air flow.  The air control valve adjust speeds between 300-3000 RPM.  The air motor is connected to the 1" diameter x 36" long mixing shaft by a stainless steel coupler.  A heavy duty bearing adds support to maximize shaft stability.  At the end of the mixing shaft are (2) 5" diameter, 3-blade square pitch propellers which attach to the shaft with set screws and provide outstanding fluid velocity.  All wetted parts are 316 SS for chemical resistance.  This model features a Baldor motor known for quality and reliability.  Many custom options are available for our heavy duty flange mount mixers including washdown duty, explosion proof or stainless steel motors, variable speed control (VFD), customized seals, special shafts and alternate impellers.  Please contact one of our engineers to quote your specific application needs.

Motor

Impeller

Mount

Shaft

General

Model Number: FM-150A

INDCO's deluxe heavy duty flange mount mixers are an excellent choice for mixing in large scale process vessels or anywhere sealed mixing is required.  Simply the best value in the industry for this type of mixer,  the FM-075A model features a 304 stainless steel 4" ANSI flange mount design and a dry-running mechanical seal rated 125 psi to full vacuum.  The 1-1/2 HP air motor provides maximum agitation when supplied with 100 PSI @ 70 CFM.  See our air motor performance guide for operation at lower air flow.  The air control valve adjust speeds between 300-3000 RPM.  The air motor is connected to the 1" diameter x 36" long mixing shaft by a stainless steel coupler.  A heavy duty bearing adds support to maximize shaft stability.  At the end of the mixing shaft are (2) 5" diameter, 3-blade square pitch propellers which attach to the shaft with set screws and provide outstanding fluid velocity.  All wetted parts are 316 SS for chemical resistance.  This model features a Baldor motor known for quality and reliability.  Many custom options are available for our heavy duty flange mount mixers including washdown duty, explosion proof or stainless steel motors, variable speed control (VFD), customized seals, special shafts and alternate impellers.  Please contact one of our engineers to quote your specific application needs.

Motor

Impeller

Mount

Shaft

General


$4,350.00
Approx. Lead Time
20 Business Days
* Orders in quantity or with other items may extend lead times.
