1 HP Electric 5 Gallon Heavy Duty Mixer

1 HP Electric 5 Gallon Heavy Duty Mixer Image
1 HP Electric 5 Gallon Heavy Duty Mixer Image

Model Number: FGM-1T

Part Number: 21A6304

Our 5-gallon heavy-duty mixer mounts directly to pails up to 12-1/4" wide with its ring mount design and two handles.  The high-torque 5:1 gear reducer vigorously agitates heavy viscosity materials.  The quick-change coupler and shaft design features a shaft pin that locks in place during rotation.  The three 9" two-blade 319 aluminum propellers attach to the 15" long shaft with set screws.
The FGM-1T model features a 1 HP totally-enclosed fan cooled motor that is ready to plug into a standard outlet.  This model operates at a fixed speed of 350 RPM. This electric model features an ABB or an equivalent brand motor.

Motor

Horsepower 1
Motor Enclosure Totally Enclosed Fan Cooled
MotorRPM 1750
Motor Type Electric
Baldor Model or Equivalent VL3510
IPTS Model RPQ1-5-56C
Motor Frame 56C Face
Motor Exterior Painted
Rotation Top Wired Clockwise
Phase Single
Voltage 115/230
Hertz 60
FL Amps 12.8:6.4
ServiceFactor 1.00
InsulationClass F
Gearbox Ratio 5:1
Gearbox RPM 350

Impeller

Quantity 3
Diameter 9"
Style 2-Blade
Bore 5/8"
Rotation Left Hand
Material Construction Aluminum
Blade Construction Cast
Set Screw 2

Mount

Construction Steel
Features Ring Mount for pails up to 12-1/4" Wide

Shaft

Exposed Dimensions 5/8" x 15"
Construction 316 Stainless Steel

Model Number: FGM-1T

Our 5-gallon heavy-duty mixer mounts directly to pails up to 12-1/4" wide with its ring mount design and two handles.  The high-torque 5:1 gear reducer vigorously agitates heavy viscosity materials.  The quick-change coupler and shaft design features a shaft pin that locks in place during rotation.  The three 9" two-blade 319 aluminum propellers attach to the 15" long shaft with set screws.
The FGM-1T model features a 1 HP totally-enclosed fan cooled motor that is ready to plug into a standard outlet.  This model operates at a fixed speed of 350 RPM. This electric model features an ABB or an equivalent brand motor.

Motor

Horsepower 1
Motor Enclosure Totally Enclosed Fan Cooled
MotorRPM 1750
Motor Type Electric
Baldor Model or Equivalent VL3510
IPTS Model RPQ1-5-56C
Motor Frame 56C Face
Motor Exterior Painted
Rotation Top Wired Clockwise
Phase Single
Voltage 115/230
Hertz 60
FL Amps 12.8:6.4
ServiceFactor 1.00
InsulationClass F
Gearbox Ratio 5:1
Gearbox RPM 350

Impeller

Quantity 3
Diameter 9"
Style 2-Blade
Bore 5/8"
Rotation Left Hand
Material Construction Aluminum
Blade Construction Cast
Set Screw 2

Mount

Construction Steel
Features Ring Mount for pails up to 12-1/4" Wide

Shaft

Exposed Dimensions 5/8" x 15"
Construction 316 Stainless Steel

$1,388.50
Approx. Lead Time
2 Business Days
* Orders in quantity or with other items may extend lead times.
