30" Dia. X 5/8" Center Hole Type A 304 SS Dispersion Blade - Coated

30" Dia. X 5/8" Center Hole Type A 304 SS Dispersion Blade - Coated Image

Model Number: DB30AT

Part Number: 21C1144

The tungsten carbide coated Design A dispersion blade features alternating teeth with angled leading and trailing edge profile for high shear action. Our most popular blade design is the performance match for the Cowles ® design and is the standard for a broad range of dispersion applications. Tungsten carbide coating provides an extremely hard surface for extended blade life or added durability when used with highly abrasive materials. The 30" diameter blade is laser cut from 304 stainless steel, has a 5/8" center hole and is die formed. We can provide 316 stainless steel blades by request. All our dispersion blades can be supplied with mounting hole patterns to match your equipment requirements. Optional mounting hubs are also available and include welded or bolted designs. Please see our guide to ordering dispersion blades or contact customer service.

Impeller

General

Model Number: DB30AT

The tungsten carbide coated Design A dispersion blade features alternating teeth with angled leading and trailing edge profile for high shear action. Our most popular blade design is the performance match for the Cowles ® design and is the standard for a broad range of dispersion applications. Tungsten carbide coating provides an extremely hard surface for extended blade life or added durability when used with highly abrasive materials. The 30" diameter blade is laser cut from 304 stainless steel, has a 5/8" center hole and is die formed. We can provide 316 stainless steel blades by request. All our dispersion blades can be supplied with mounting hole patterns to match your equipment requirements. Optional mounting hubs are also available and include welded or bolted designs. Please see our guide to ordering dispersion blades or contact customer service.

Impeller

General


$1,349.00
Approx. Lead Time
4 Business Days
* Orders in quantity or with other items may extend lead times.
Add To Cart
